SCM 10HP 3-Phase 16" Industrial Cabinet Saw - TA16B

SCM 10HP 3-Phase 16" Industrial Cabinet Saw - TA16B

$4,882.99
$4,882.99 $6,510.00
SAVE 24% Sold out
SCM 10HP 3-Phase 16" Industrial Cabinet Saw - TA16B

SCM 10HP 3-Phase 16" Industrial Cabinet Saw - TA16B

$4,882.99
$4,882.99 $6,510.00
SAVE 24% Sold out

SCM 10HP 3-Phase 16" Industrial Cabinet Saw - TA16B

Cantek TA series table saws are built for serious woodworkers. This 16" table saw boasts a 10HP, 3-phase motor that delivers the power you need to cut through material as thick as 5-1/2" (at 90°). Ideal for medium-sized production shops.

The large precision-ground & polished cast-iron table and saw unit ensure vibration-free cutting with optimum quality. The TA16B comes standard with a T-square rip fence equipped with a single locking lever to ensure the fence is square every time. The fence is set accurately in place by a dual metric/inch scale, which features a magnifying glass for easy visibility.

Safety is key on the TA16B. This saw is equipped with a clear blade guard that adjusts to the height of the workpiece. The guard also has a built-in splitter and anti-kickback fingers to protect the operator. Blade height and angle adjustments are made via the two handwheels on the machine. The blade can tilt from 0 - 45° to the right.

The TA16B includes a miter gauge that runs in a T-slot on either the left or right side of the blade. It also comes with a removeable 1" arbor and additional 1" dado arbor extension & throat plate.

Features
  • Heavy-duty cast iron table is precision ground for accuracy & precision
  • Industrial strength cast iron saw carriage and trunnion for vibration free cutting
  • 50” capacity T-square rip fence assembly locks on front rail for a precise parallel reference to the saw blade
  • Right tilt blade to 45°
  • Dual Inch/Metric scale guide rail on rip fence with magnifying glass for easy visibility
  • Miter gauge with two miter slots in the table
  • Comes with dado arbor & dado table insert
  • 16” blade can be lowered completely under the table
  • Rugged machine frame construction provides maximum stability and reduced vibration
  • Saw guard with built in splitter and safety anti-kickback unit
  • 1” standard and 1” dado arbor included along with appropriate cast iron table inserts
  • Handwheel adjustment for blade height and tilting adjustments which can be locked in place
  • CSA / UL approved magnetic switch
What our Experts Think
  • Heavy-Duty 10HP Performance – Engineered for demanding industrial woodworking applications, providing the power needed to cut thick hardwoods, composites, and large sheet materials with ease.
  • Large 16" Blade Capacity – Offers increased cutting depth and versatility, making it ideal for production shops handling a wide range of woodworking tasks.
  • Industrial 3-Phase Operation – Delivers smooth, reliable power for continuous commercial use, helping maintain productivity in high-volume manufacturing environments.
  • Exceptional Accuracy & Stability – The cabinet-style design minimizes vibration and supports precise, repeatable cuts for furniture making, cabinetry, and custom millwork.
  • Built for Long-Term Shop Use – Constructed with industrial-grade components to withstand rigorous daily operation while maintaining consistent performance.
Q&A

Q: What is the SCM TA16B Industrial Cabinet Saw used for?
A: The TA16B is a professional-grade cabinet saw designed for precision ripping, crosscutting, panel processing, and heavy-duty woodworking applications.

Q: What are the advantages of a 16-inch blade capacity?
A: The larger blade size allows for deeper cutting capacity, greater versatility, and efficient handling of thick or oversized materials.

Q: Is the TA16B suitable for industrial woodworking environments?
A: Yes. It is engineered for commercial workshops, furniture manufacturers, cabinet makers, and production facilities requiring reliable cutting performance.

Q: What type of power does this machine require?
A: The TA16B is powered by a 10HP three-phase motor, providing the strength needed for demanding, continuous-duty operations.

Q: Can it cut hardwoods and large wood panels?
A: Yes. The powerful motor and heavy-duty construction make it ideal for hardwoods, plywood, MDF, and other sheet materials.

Q: How does a cabinet saw improve cutting accuracy?
A: Its rigid cabinet structure, precision fence system, and stable work surface help ensure smooth, accurate, and repeatable cuts.

Q: Is this saw designed for high-production workloads?
A: Yes. The TA16B is built to withstand continuous operation in busy professional and industrial woodworking environments.

Q: Who is this machine best suited for?
A: Professional woodworkers, cabinet shops, furniture manufacturers, millwork operations, and industrial woodworking facilities seeking maximum power and precision.

Maintenance Tips
  • Clean the saw table, blade housing, cabinet interior, and dust collection ports after each use.
  • Inspect the 16" saw blade regularly for dull teeth, damage, or resin buildup and service or replace as needed.
  • Keep the dust extraction system clear and operating efficiently to reduce debris accumulation and improve performance.
  • Check blade alignment, rip fence accuracy, and arbor runout periodically for precise cutting results.
  • Lubricate trunnions, tilt mechanisms, height adjustments, and other moving components according to the manufacturer's guidelines.
  • Inspect drive belts for wear, cracking, or incorrect tension and adjust or replace when necessary.
  • Verify all electrical connections, controls, and motor components are secure and functioning properly.
  • Protect the cast-iron table surface with a suitable rust inhibitor or machine wax to ensure smooth material feeding.
  • Test blade guards, emergency stops, riving knives, and safety devices regularly.
  • Operate and store the machine in a clean, dry environment to maximize reliability and service life.
